Custom Automatic Conversions

Dodge NV4500 Transmission

Convert your Dodge NV4500 to an Allison

Transform Your Drive: Making the Switch to an Allison 1000PK Transmission

Drive with confidence and efficiency by making the upgrade to an Allison 1000PK Transmission. Known for their unrivaled reliability and superior performance, Allison transmissions are a popular choice among car enthusiasts and professionals alike. In this guide, we will explore the process of converting your current transmission system to an Allison 1000PK. We'll delve into the benefits of this upgrade, why it could be the best choice for your vehicle, and how this switch could dramatically enhance your driving experience. Get ready to transform your ride with the power and durability of an Allison 1000PK Transmission.

NV4500 Transmission: An Overview, Key Features, and Common Concerns

Overview of the NV4500 Transmission

The Dodge NV4500 transmission, often referred to simply as the "NV4500," is a heavy-duty, manual five-speed transmission. Manufactured by New Venture Gear, it was introduced in the early 1990s and has been widely used in Dodge Ram 2500 and 3500 series pickup trucks.

Known for its exceptional durability and strength, the NV4500 is often the go-to transmission for applications that require heavy-duty towing or hauling capabilities. It's particularly revered among off-road enthusiasts for its robustness and ability to handle high torque outputs.

The NV4500 features a cast-iron case, a highly efficient cooling system, and synchronized gears. The design incorporates helical gears, making it quieter and smoother than many other manual transmissions. While it's respected for its longevity and toughness, like any component, it can wear down over time, prompting the need for rebuilding, replacing, or even considering an upgrade such as converting to an Allison 1000PK transmission.

NV4500 Features

The Dodge NV4500 Transmission, manufactured by New Venture Gear, is known for its robust construction and high-performance features. Let's delve into its key specifications and features:

5-Speed Manual Transmission: The NV4500 is a manual transmission with five forward gears, including a low first gear and overdrive 5th gear. This gives drivers greater control over their vehicle's performance.
High Torque Capacity: This transmission is built to handle high torque outputs, making it ideal for heavy-duty applications such as towing or off-road use.
Cast Iron Case: The NV4500 features a cast-iron case, ensuring robustness and durability. This makes it a favored choice for vehicles that require a sturdy, reliable transmission.
Helical Gears: The NV4500's design includes helical gears, making it smoother and quieter during operation compared to transmissions with straight-cut gears.
Synchronized Gears: With all gears being synchronized, shifting is smoother, and there's less chance of damaging the transmission due to mishandling.
Integrated Cooling System: The NV4500 includes an efficient cooling system, essential for managing the heat produced during operation, thereby prolonging its lifespan.
High Weight: The NV4500 is heavier than many other transmissions, which is a testament to its durability but may impact fuel efficiency.

The NV4500 has garnered a reputation for being a workhorse in the world of transmissions, often outperforming others in terms of reliability and strength. However, like any component, it may require maintenance, repair, or eventually an upgrade such as a conversion to an Allison 1000PK transmission for even better performance.

NV4500 Common Issues and Signs of Failures

While the Dodge NV4500 transmission is known for its durability and strength, it's not immune to wear and tear. Here are some common issues and symptoms that might indicate a failing NV4500 Transmission:

Difficulty in Shifting Gears: Struggling to shift gears or experiencing hard shifts can be a sign of worn synchronizers or other internal transmission components.
Unusual Noises: If you start hearing unfamiliar sounds like grinding or whining coming from your transmission, it could indicate problems with the bearings, gears, or other parts.
Transmission Fluid Leaks: If you spot leaks under your vehicle, it might be transmission fluid. Leaks can occur from worn seals or gaskets, and if not promptly addressed, can lead to serious transmission damage.
Transmission Popping Out of Gear: This can occur due to wear and tear on internal components like synchronizers or shift forks. If the transmission slips out of gear while driving, it could be a signal of a failing transmission.
Excessive Heat: Transmissions naturally produce heat, but excessive heat could point to issues such as low fluid levels, clogged cooler lines, or internal damage.
Vehicle Doesn't Move: If the vehicle doesn't move when you shift into gear, it might indicate a severe transmission issue, potentially involving the clutch, gears, or other components.

Your Guide to Rebuilding, Replacing, and Upgrading to an Allison Transmission

Rebuild, Replace, Converting to an Allison

Convert to Allison

Converting to an Allison 1000PK Transmission

Converting your Dodge vehicle to an Allison 1000PK Transmission can bring about enhanced durability, reliability, and performance. The Allison 1000PK is renowned for its ability to handle high torque applications, making it an excellent choice for heavy-duty and towing scenarios. Here's a general overview of the conversion process:

Removal of the Existing Transmission: The first step involves removing your existing NV4500 transmission from the vehicle. This includes disassembling the drivetrain components, fluid lines, and electrical connectors.
Preparation for the Allison 1000PK: Once the existing transmission is removed, the vehicle needs to be prepared for the Allison conversion. This can include modifications to the transmission mounts, driveshaft, cooling lines, and electrical systems to accommodate the new transmission's specifications.
Installation of the Allison 1000PK: The Allison transmission is then installed in place of the old unit. It needs to be carefully aligned with the engine and driveshafts, then securely bolted in place.
Integration of the Allison TCM and CAC TCM: The Allison Transmission Control Module (TCM) and proprietary CAC TCM need to be installed and integrated into the vehicle's existing systems. These control units are vital for synchronizing the Allison transmission with your vehicle.
Testing and Calibration: After the Allison 1000PK is installed, it's necessary to carry out comprehensive testing and calibration. This includes checking for any leaks, ensuring correct gear operation, and adjusting the TCM for optimal performance.

Conversion to an Allison 1000PK is a complex task best left to trained professionals. But once completed, you will enjoy enhanced transmission performance and reliability that will serve your vehicle well in the long run.

NV4500 Rebuild

Rebuilding the Dodge NV4500 Transmission

Rebuilding the Dodge NV4500 transmission can be a complex task but is often necessary when the unit has experienced significant wear or damage. Here's a general overview of what the process entails:

Disassembly: The first step is to remove the transmission from the vehicle, followed by the careful disassembly of the unit. Each component is removed, inspected, and cleaned. This includes the gearsets, bearings, synchros, shift forks, and casing.
Inspection: Each part is meticulously examined for signs of wear, damage, or failure. Components such as bearings, seals, and gaskets are typically replaced in the rebuilding process, regardless of their condition, to ensure the longevity of the rebuild.
Repair or Replacement of Components: Any damaged or excessively worn parts are either repaired or replaced. The quality of the replacement parts can significantly affect the overall longevity and performance of the rebuilt transmission.
Reassembly: Once all components are repaired or replaced, the transmission is reassembled. This is a precision task, as every component must be correctly aligned and torqued to specification.
Testing: After reassembly, the transmission is typically tested to confirm that it operates correctly. This can include bench tests, hydraulic pressure tests, and finally road testing after the transmission is reinstalled.

The rebuilding process requires a strong understanding of the transmission's operation, and it is often best left to trained professionals. It's also worth noting that a rebuild is a good opportunity to make any upgrades or improvements to the transmission, such as converting to a more robust and reliable Allison 1000PK transmission.

Replace NV4500

Replacing the Dodge NV4500 Transmission

Replacing a Dodge NV4500 transmission can be a viable solution when it becomes uneconomical or impossible to repair or rebuild the existing unit due to extensive wear or damage. Here's a general breakdown of the replacement process:

Removal: First, the faulty NV4500 transmission is detached from the vehicle. This involves disconnecting the drivetrain components, electrical connectors, and fluid lines, then carefully lowering the transmission from the vehicle.
Inspection: The old transmission should be thoroughly inspected to identify any potential causes of failure that could impact the new transmission. This can include issues with the cooling system, electronic controls, or drive shaft alignment.
Preparation of the Replacement Transmission: The new or refurbished NV4500 transmission should be prepared for installation. This includes checking it for any damage incurred during shipping, ensuring it has been correctly assembled and cleaned, and installing any necessary components that didn't come with the new unit.
Installation: The new transmission is carefully raised into position and connected to the vehicle. This involves aligning it with the engine and drive shafts, connecting the fluid lines and electrical connectors, and bolting it securely in place.
Testing: After installation, the new transmission should be thoroughly tested. This includes checking for leaks, verifying correct operation of all gears, and ensuring smooth and correct shifting.

Replacing a transmission is a complex task that requires specialist tools and knowledge. It's generally recommended that this process is carried out by experienced professionals to ensure it's done correctly. Keep in mind that an Allison 1000PK transmission can also be considered as a replacement, providing improved durability and performance.

Benefits of converting to an Allison 1000PK Transmission

Transitioning to an Allison 1000PK Transmission comes with numerous benefits that enhance the overall performance and reliability of your vehicle. Here are some key advantages

Superior Durability

Allison 1000PK transmissions are built to withstand high torque and heavy-duty applications, making them an excellent choice for vehicles frequently used for towing or hauling heavy loads. Their robust construction ensures they can handle the strain better than many standard transmissions.

Increased Reliability

The Allison 1000PK is renowned for its reliable performance, even under demanding conditions. With proper maintenance, Allison transmissions are less likely to encounter issues, leading to fewer breakdowns and less downtime for your vehicle.

Better Fuel Efficiency

Thanks to their precise engineering and advanced control modules, Allison transmissions can often deliver improved fuel efficiency. This can lead to significant savings in fuel costs over time.

Smooth Performance

The Allison 1000PK provides smooth, precise shifting, enhancing your driving experience. This can be especially beneficial in heavy-duty or commercial applications where vehicles are often in use for long periods.

Potential Increase in Resale Value

Vehicles equipped with Allison transmissions are often seen as more desirable, potentially increasing the resale value of your vehicle.

Ease of Maintenance

Allison transmissions have been designed with ease of maintenance in mind. This, combined with their robustness and reliability, can lead to lower overall maintenance costs.

What's included in an Allison Conversion kit?

We provide everything you will need to get the swap done right

- Kit Includes

Allison 1000PK Transmission

Upgrade your vehicle's capabilities with the esteemed Allison 1000PK Transmission. You have the option to either include this component in your kit purchase or use your own pre-acquired Allison 1000PK transmission. To cater to your needs, we also provide transmission rebuilding services. Explore a comprehensive selection of other Allison transmissions here that we can expertly convert.

Torque Converter to fit your needs

Ensure efficient transmission of power from your engine with our durable torque converter. It's a critical component in your Allison conversion, facilitating smooth acceleration and better fuel economy.

Wiring Harness

Guarantee the seamless transmission of electrical signals with our robust wiring harness. It's specifically designed for Allison conversions, ensuring dependable and efficient communication within your vehicle's systems.

Flex Plate Adapter

The flex plate adapter in our kit ensures a reliable connection between the engine and transmission. It's essential for smooth operation and longevity of your vehicle's drivetrain.

Transfer Case Adapter, Couplers, and Tone Rings

Our kit includes T-case adapters, couplers, and tone rings to ensure a secure and efficient link between your transmission and transfer case. These components are key to maintaining the integrity and performance of your 4WD system.

Mounting Kit and Shift Linkage

This kit offers a comprehensive mounting setup and shift linkage to ensure your Allison transmission is firmly secured and smoothly operable. They are essential components for a successful and reliable Allison conversion.

Cooling Kit

Keep your Allison transmission operating at optimal temperatures with our dedicated cooling kit. Efficient heat management is key to maintaining the longevity and performance of your vehicle's transmission system.

CAC Digital Display

Monitor your transmission's performance in real time with our optional digital display. This intuitive feature provides critical data at a glance, ensuring you always stay informed about your vehicle's transmission status.

Allison Total Control Module (TCM)

Maximize your truck's efficiency with Allison's Transmission Control Module (TCM). It is designed to provide seamless gear shifts and optimal performance, enhancing your driving experience.

CAC Total Control Module (TCM)

Our proprietary CAC TCM works in sync with the Allison transmission to ensure flawless operation for the vehicles we provide kits for. This module plays a crucial role in optimizing your vehicle's transmission control system.

NV4500 Allison Conversion Kits

Browse Allison Conversions

1994-1998 Dodge Cummins P Pump NV4500 4X4 Manual

1994-1998 Dodge Cummins P Pump NV4500 2WD Manual

How to determine the Right Torque Converter

Maximizing Performance: Using Tire Diameter and Gear Ratio Calculations to Choose the Ideal Torque Converter

Get Started What is a Torque Converter?

How to determine the right torque converter

FAQ'S

What are the benefits of converting my Dodge Ram's current transmission to an Allison?

Converting your Dodge Ram's transmission to an Allison can result in numerous benefits including improved durability, enhanced towing capability, increased fuel efficiency, and smoother gear shifts, thus optimizing your vehicle's performance.

Is an Allison conversion compatible with all Dodge Ram models?

Most Dodge Ram models can benefit from an Allison transmission conversion, but it's advisable to consult with a specialist to ensure compatibility with your specific model.

Can I use my existing Dodge Ram transfer case with an Allison conversion?

Yes, with the right adapters, your existing Dodge Ram transfer case can be utilized in an Allison conversion.

Which Allison transmissions are best suited for Dodge Ram vehicles?

The Allison 1000 series is a popular choice for Dodge Ram vehicles due to its reliability and performance, but the best option depends on your particular needs and vehicle model.

What is the process for converting my Dodge Ram's transmission to an Allison?

The conversion process involves removing your Dodge Ram's current transmission, fitting the Allison transmission with the necessary adapters, and installing it. The wiring harness, TCM, and other components are also adjusted accordingly.

Will my Dodge Ram's performance and fuel economy improve with an Allison transmission conversion?

Yes, an Allison transmission is designed to provide smoother shifts, increased durability, and better fuel efficiency, all of which contribute to improved vehicle performance.

What specific components come with the Allison conversion kit for Dodge Ram vehicles?

An Allison conversion kit typically includes components such as the transmission (if chosen), TCM, torque converter, wiring harness, adapters, and other necessary parts for the conversion.

Can I provide my own Allison transmission for the conversion, or can it be included in the kit?

You have the option to either provide your own Allison transmission or include it with your conversion kit purchase.

Can I perform the Allison transmission conversion myself, or do I need a professional?

While it's possible for experienced individuals to do the conversion, it's generally recommended to hire a professional to ensure the job is done correctly and safely.

How long does a typical Allison conversion take for a Dodge Ram?

The conversion time can vary based on the vehicle and the specific conversion kit. On average, it might take a few days to complete.

Will converting my Dodge Ram's transmission to an Allison affect my warranty?

An Allison conversion could affect your vehicle's warranty depending on the specific terms of your warranty agreement. We recommend checking with your warranty provider before proceeding with the conversion.

What should I do if I encounter issues after converting my Dodge Ram's transmission to an Allison?

If you face any problems after the conversion, it's best to contact your conversion specialist for troubleshooting assistance or potential service needs.

Can I use an Allison transmission from a different vehicle (like a Chevrolet/GM) for my Dodge Ram conversion?

Yes, an Allison transmission from another vehicle can be used, provided it's compatible with your Dodge Ram model. Ensure to consult with your conversion specialist before proceeding.

Do you offer rebuilding services for Allison transmissions?

Yes, we do offer rebuilding services for Allison transmissions, ensuring your transmission is operating at peak performance.

What is the cost range for an Allison transmission conversion for Dodge Ram vehicles?

The cost can vary significantly depending on the specific Allison model, whether you're providing the transmission or purchasing it as part of the kit, and any additional services required. Please contact us directly for a more precise estimate.
